Welcome to the AMICS online help. The exhaustive work of the AMICS Team from Hitachi Hightech Canada and Bruker BNA has made this possible. Please remember that this is always a work in progress, and any additions can be requested by emailing

This manual is for AMICS Investigator, AMICS Process, and AMICS Tool. See

 for the Hitachi SI Reports manual. This separate, free software can be used for to access the AMICS

 to make data dashboards and printed reports.

Upgrades within any version of AMICS 5.x are always free to AMICS customers. See

If you have any issues, please email the AMICS support email address or contact your local sales channel.

Open AMICS Tools once you have installed and updated. This is required for fresh installs. It will update the user database and repair any damage.

This online HTML-based help manual replaces and supersedes any previous manual. Please note that this manual is for AMICS on M4, SEM, and EMPA. Differences between X-ray and electron sources will be noted. Topics that only apply to SEM will be marked with (

), and topics that only apply to micro-XRF will be marked with (

The following warning symbols and informational symbols, as well as signal words, are used in this operating instruction:
